Maintenance of lubrication part of machine tool for machining mechanical parts

Return list Browse times : 29 Release date : 19.06.13

   Stay Parts processing and customized service center , The lubricating parts of the machine tool must be oiled regularly according to the lubrication drawing , The injected lubricating oil must be clean 。 The lubricating part shall be oiled once a week , Find out the law of fuel consumption , In case of any decrease in oil supply, the maintenance personnel shall be informed in time for maintenance 。 Machining of mechanical parts The operator should pay attention at any time CRT Moving axis monitoring screen on the display , When abnormal phenomena such as current increase are found , Inform the maintenance workers in time for maintenance 。 The maintainer shall check the lubricating oil distribution device once a year , Dredge or repair in time in case of oil blockage or leakage 。

 Machining of mechanical parts

   Stay Parts processing and customized service center , The lubricating oil in the base must be added to the highest line of the oil mark , To ensure the normal operation of lubrication 。 Therefore , The oil level must always be checked for correctness , Lubricating oil should be 5~6 Replace once a month 。 Due to the large initial wear of all parts of the new machine tool , Therefore , The time of the first and second oil change shall be advanced to once a month , In order to remove the dirt in time 。 After the waste oil is discharged , Inside the box ( Including headstock and oil tank in the base ) Clean with kerosene , Clean or replace the oil filter at the same time 。


   Stay Parts processing customization In process , Sealing of pneumatic system is very important 。 When the air enters the reversing valve, it will adhere Stay Valve center , Gradually reduce the sensitivity of the valve , Even present action failure 。 To remove sludge , Guaranteed sensitivity , After the filter of the pneumatic system , Installing oil mist separator , Separate the sludge 。 In addition , Regular cleaning of the hydraulic network can also ensure the sensitivity of the valve 。


   Ensure that the pneumatic device has proper working pressure and moving speed , When adjusting the working pressure , Pressure gauge should be reliable , Accuracy of reading 。 After the pressure reducing valve and throttle valve are adjusted , The pressure regulating valve cover or lock nut must be tightened , Prevent loosening 。 Check whether the pressure of compressed air is normal every day ; Filter needs manual drainage , Once every two days in summer , Once a week in winter ; Check whether the lubricating oil in the lubricator is used up every month , Add lubricating oil of specified brand in time 。
